Size | W145×D100×H42mm |
---|---|
Weight | Approx. 500g * Not including accessories. |
USB ports | 2 |
USB connectable devices | – USB memory for recording – Wi-Fi adapter |
# of inputs | 2 Port * Power supply redundancy is supported. |
---|---|
Connector | USB Type-C |
Voltage | 5V |
Max. current | 3A |
Compatible power supply equipment | AC Adaptor or mobile battery |
Protocol Support | RTMP/RTMPS Client RTSP Server MPEG2-TS over UDP |
---|---|
Simultaneous Streaming | 3ch * Each stream uses the same encoder quality settings. * Max. 2 simultaneous streams if the recording function is enabled. |
Recording Media | microSD card (SDHC standard up to 32GB) USB memory (USB2.0 High-Speed standard, FAT32 format) * SD slot does not support SDXC cards. * Recording with a microSD card and USB memory are exclusive functions and cannot be used simultaneously. |
Recording stream | Same encoder stream as output |
Video | Video compression | H.264 |
---|---|---|
Max. resolution | 1920 × 1080 | |
Max. frame rate | 60FPS | |
Bitrate output range | 128 ~ 20,480 kbit/s | |
Audio | Audio encoding | AAC-LC |
# of channels | 2 | |
Sampling rate | 48kHz | |
Audio bit depth | 16bit | |
Bitrate output range | 48 ~ 256kbit/s |
Video | # of inputs | 2 |
---|---|---|
Video input | HDMI * HDCP is not supported. | |
Input format | 1080p/60(59.94), 1080p/50, 1080p/30(29.97), 1080p/25, 1080p/24(23.976), 1080i/60(59.94), 1080i/50, 720p/60(59.94), 720p/50, 720p/30(29.97), 720p/25, 720p/24(23.976), 576p/50, 480p/59.94, VGA * Each HDMI input must use the same input format. | |
Deinterlacer | Field combination * Interlaced input will be automatically converted to progressive output. * Interlaced output is not supported. | |
Digital audio | # of inputs | HDMI x2, USB x1 |
Audio input | HDMI Audio (shared with video input) USB Audio Class * USB audio interface (sold separately) is required for USB input. * USB input will be enabled in a future firmware update (fall 2022 or later). | |
Analog audio | # of inputs | 2 |
Input connector | LINE In, MIC In * The audio inputs can be mixed with HDMI audio |
Video | # of outputs | 1 * Used to check the live streaming output. |
---|---|---|
Video output | HDMI | |
Output formats | 1080p/60(59.94), 1080p/50, 1080p/30(29.97), 1080p/25, 1080p/24(23.976), 720p/60(59.94), 720p/50, 720p/30(29.97), 720p/25, 720p/24(23.976), 576p/50, 480p/59.94, VGA * The output format will be the same as the input. * Interlaced input will be automatically converted to progressive output. | |
Digital audio | # of outputs | 1 |
Digital audio output | HDMI Audio (same as video output) |
Switching | # of video inputs | 2 |
---|---|---|
Effect | CUT, MIX, WIPE | |
Video mixing | Effect | PinP, Chroma key |
Lower thirds | Caption, text placement, PNG image * Supported only in full screen. * Only full screen images are supported. * Free text and image placement will be supported in a future update. |
Unit operation | Display | 128 x 64 dots OLED display |
---|---|---|
Power operation | Power button | |
Menu operation | Control dial, Memory button | |
Video/streaming operation | Streaming control button, A/B switch button | |
External operation | Buit-in HTTP Server | Control with application on PC or tablet connected wirelessly or via Ethernet |
Installed Application | LiveShell Studio |
Ethernet | Connection interface | 10BASE-T/100BASE-TX/1000BASE-T |
---|---|---|
# of ports | 1 | |
Wireless | Connection interface | Wireless LAN(802.11a/b/g/n/ac)/LTE * Wireless LAN Adapter required. |
Wireless LAN | Infrastructure mode or AP mode | |
Network protocal | IPv4 / IPv6 | |
Address settings | DHCP or fixed IP (IPv4), SLAAC (IPv6) |
Included | LiveShell W, Quick Set Up Guide, AC Adapter, USB Type C cable for power supply, Wi-Fi Adapter |
---|---|
Package | Carrying Case |
Model | CDP-LS05A |
Release | June 2022 |
Price | $899.00 / €999.00 |
